Moda Spring Hinge - Satin Chrome Plate

Material	Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers
Finish	Satin Chrome Plate
Mounting	Concealed Screw Fix or Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges	35mm
Specify	MODA_LHSPRING_SCP: Left Hand MODA_RHSPRING_SCP: Right Hand
Features	Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability
Load Rating	15Kg per hinge
	For optimum performance - 2 hinges per door up to 30Kgs For doors over 30Kg allow for 15Kg per hinge Note: 3 Hinges per door is recommended to prevent door bowing
Note	For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings. Please nominate your requirements at the time of ordering.

$8.65

Original: $24.72

Moda Spring Hinge - Satin Chrome Plate—

$24.72

$8.65

Original: $24.72

Moda Spring Hinge - Satin Chrome Plate—

$24.72

$8.65

Material	Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers
Finish	Satin Chrome Plate
Mounting	Concealed Screw Fix or Bolt Through
Minimum Hinge Clearance For Lift-Off Hinges	35mm
Specify	MODA_LHSPRING_SCP: Left Hand MODA_RHSPRING_SCP: Right Hand
Features	Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability
Load Rating	15Kg per hinge
	For optimum performance - 2 hinges per door up to 30Kgs For doors over 30Kg allow for 15Kg per hinge Note: 3 Hinges per door is recommended to prevent door bowing
Note	For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings. Please nominate your requirements at the time of ordering.
